Standard Tinned Duplex Cable

Ancor

ART-121110-ANC

MPN: 121110

$193.36
$193.36
Sale Sold out
Tax included. Shipping calculated at checkout.
Wire Gauge
Length
View full details

About this product

Ancor safety duplex cable features red and yellow Marine Grade primary conductors (correctly color-coded to ABYC standards) in a white common jacket that is made for easy removal while providing the best abrasion resistance available.

These cables exceed UL 1426 standards and are made from the highest quality ultra flexible (Type 3/Class K) tinned copper stranding that provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.

The premium vinyl insulation provides long-lasting durability and performance in marine environments.

Key Features

  • Highest quality ultra flexible (Type 3) tinned copper stranding
  • Provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing
  • Exceeds UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards
  • Constructed with premium vinyl insulation rated at:
  • 600 volts
  • 105° C dry
  • 75° C wet
  • Stays flexible even in extreme cold (-40° F/C)
  • Resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation


Technical Specification

Wire colors
Black and red
Wire material
Tinned copper
Certification
Exceeds UL 1426 for marine pleasure craft

No Documentation available.

SKU # Part # Wire Gauge Length Price Quantity
SKU #: ART-121110-ANC Wire Gauge: 10 AWG Length: 100ft $193.36
- +
SKU #: ART-121125-ANC Wire Gauge: 10 AWG Length: 250ft $328.99
- +
SKU #: ART-121140-ANC Wire Gauge: 10 AWG Length: 400ft $736.40
- +
SKU #: Wire Gauge: 10 AWG Length: 500ft $0.00
- +
SKU #: ART-121310-ANC Wire Gauge: 12 AWG Length: 100ft $132.04
- +
SKU #: ART-121325-ANC Wire Gauge: 12 AWG Length: 250ft $229.09
- +
SKU #: Wire Gauge: 12 AWG Length: 400ft $0.00
- +
SKU #: ART-121350-ANC Wire Gauge: 12 AWG Length: 500ft $617.44
- +
SKU #: ART-121510-ANC Wire Gauge: 14 AWG Length: 100ft $92.48
- +
SKU #: ART-121525-ANC Wire Gauge: 14 AWG Length: 250ft $162.49
- +
SKU #: Wire Gauge: 14 AWG Length: 400ft $0.00
- +
SKU #: ART-121550-ANC Wire Gauge: 14 AWG Length: 500ft $424.66
- +
SKU #: ART-121710-ANC Wire Gauge: 16 AWG Length: 100ft $72.76
- +
SKU #: ART-121725-ANC Wire Gauge: 16 AWG Length: 250ft $172.50
- +
SKU #: Wire Gauge: 16 AWG Length: 400ft $0.00
- +
SKU #: ART-121750-ANC Wire Gauge: 16 AWG Length: 500ft $327.36
- +
SKU #: ART-121910-ANC Wire Gauge: 18 AWG Length: 100ft $57.80
- +
SKU #: ART-121925-ANC Wire Gauge: 18 AWG Length: 250ft $135.14
- +
SKU #: Wire Gauge: 18 AWG Length: 400ft $0.00
- +
SKU #: ART-121950-ANC Wire Gauge: 18 AWG Length: 500ft $236.99
- +
