Series 285 Panel Mount Thermal Circuit Breaker

Blue Sea Systems

ART-7080B-BSS

MPN: 7080

$65.33
$65.33
Sale Sold out
Tax included. Shipping calculated at checkout.
Amperage
View full details

About this Product

The Blue Sea Systems 285-Series Panel Mount Circuit Breaker delivers reliable medium-duty protection with built-in switching for DC marine systems up to 48V. Designed as a direct upgrade to the 185-Series, it features a slow-blow, trip-free thermal design, high interrupt capacity, and waterproof, ignition-protected construction for safe, dependable operation.

Key features

  • Drop in replacement for 185-Series Circuit Breakers
  • Visible reset lever shows open condition
  • Ignition protected - Safe for installation aboard gasoline powered boats
  • Meets SAE J1171 external ignition protection requirements
  • Weather Resistant
  • Combines switching and circuit breaker function into one unit*
  • "Trip Free" - cannot be held closed after trip

* Do not use as a switch where high inrush currents are expected.

Technical Specification

Circuit Breaker Class
Type III
Interrupt Capacity
3000A @ 48V achieved using SAE J1625
Mounting
Panel Mount
Circuit Breaker Type
Thermally responsive bi-metal blade
Terminal Stud
M6 (accepts 1/4" ring terminal)
Weight
0.50 lbs (0.23 kg)

Dimension Drawings

Panel Mount 285

SKU # Part # Amperage Price Quantity
SKU #: ART-7080B-BSS Amperage: 25A $65.33
- +
SKU #: ART-7081B-BSS Amperage: 30A $65.33
- +
SKU #: ART-7082B-BSS Amperage: 40A $65.33
- +
SKU #: ART-7083B-BSS Amperage: 50A $65.33
- +
SKU #: ART-7084B-BSS Amperage: 60A $65.33
- +
SKU #: ART-7085B-BSS Amperage: 70A $65.33
- +
SKU #: ART-7086B-BSS Amperage: 80A $65.33
- +
SKU #: ART-28590P-BSS Amperage: 90A $65.33
- +
SKU #: ART-7087B-BSS Amperage: 100A $65.33
- +
SKU #: ART-7088B-BSS Amperage: 120A $65.33
- +
SKU #: ART-7089B-BSS Amperage: 150A $65.35
- +
