Arco Alternator 12V 275A N62, Side Battery Post, Externally Regulated, 50mm K6 OAP

Wholesale - Artek

ART-4026-ARC

MPN: 4026

$1,041.70
$1,041.70
Sale Sold out
Tax included. Shipping calculated at checkout.
View full details

About this product

  • Replace your noisy generator!
  • Engineered for high energy production.
  • Suitable for marine, RV, military, and commercial applications.
  • Rapidly charges large battery banks.
  • Coolest operating temperatures for increased performance:Heat shedding coatingsRectifier located on housing exteriorDual cooling fansOEM components
  • Optimized for performance at idle speeds.
  • Reduces the need for a generator by creating additional power with your engine.
  • Unleash peak performance with E-Coat/Cerakote, keeping the A275L cooler for sustained amperage output.
  • For maximum performance or lithium battery charging, use the ARCO Zeus Bluetooth Alternator Regulator.
  • SAE J1171 Certified.
  • Models available with internal/external voltage regulator.
  • Proudly made in the U.S.A.

Technical Specification

Voltage
12V
Field Type
P
Output Voltage
14.1V (default)
Rotor Poles
16
Stator Size
138mm
Weight
14.9 lbs / 6.7 kg
Regulation
External Only (EX)
Finish
(Black) E-coating
Cut-In RPM
1061 Alternator RPM
Maximum Alt RPM
19,000
Battery Post
M8 Thread Post, Side Mount
Standard Pulley
49K6 (6-groove, 49mm)
Pulley Mount
17mm diameter shaft, 25mm long, threaded M17 x 1.5
Pulley Hardware
M17 x 1.5 x 24mm nut, w/ 18mm ID x 29mm OD washer (Included)
Diodes
6 positive, 6 negative, 80A Rated, Avalanche
Sustained Cruising Output (Hot, 6,000 RPM)
227 Amps
Sustained Idle Output (Hot, 3,000 RPM)
198 Amps
Max Continuous Operating Temperature
110°C / 230°F
